Fricoflex
- Açıklama
Açıklama
Usage Areas
- We guarantee the torque of the unique friction fitting “FricoFlex“ on delivery and its nearly constant torque during the whole service life.
- This quality feature is guaranteed by a cleverly thought-out material mix, the technical properties of the component parts and an automatic assembly process with integrated quality control.
Product Code
- 1.43.030.00.49 – Torque : 3 / Force Approx : 10
- 1.43.050.00.49 – Torque : 5 / Force Approx : 15
- 1.43.070.00.49 – Torque : 7 / Force Approx : 25
- 1.43.100.00.49 – Torque : 10 / Force Approx : 30
Technicial Specifications
- Fitting, completely mounted.
- Adjustment area max. 270°.
- The fitting allows a noiseless infinite range of adjustment to any desired position.
- Installation on wooden frames by means of M6 wood screws (see installation requirements).
- Installation on tubular frames of Ø 22 x 1,8 mm is possible.
- The fitting has indentations at 58 mm centers into which the tube can be crimped
- For right and left hand side
- Packing : 100 Pcs
